Description
B. Braun Intrafix® Primeline Standard IV Set – For administering all kinds of infusions
Universal IV administration sets with air vent for gravity infusions and pressure infusions with non-dedicated infusion pumps (pressure resistant up to 2 bar)
Pressure with 1.8m tubing
3-part drip chamber design
With elastic bottom chamber and transparent dome. Allows to see drop forming and constant visual monitoring of the flow rate of infusion solutions.
With Micro-Organism tight air vent filter (bacteria-tight and viral filter efficiency) with closable snap cap. Prevents the risk of contamination while venting the solution container
With fluid filter (15µm mesh size) to provide high flow rate
With clear and easy to pierce spike, featuring separated fluid inlet and air outlet to reduce risk of air entrainment
Tube
Fluid line from the infusion bottle to the patient.
Soft and clear tubing that allows observance of air bubbles.
Standard dimensions: lumen 3 x 4.1 mm and length 180cm
Roller clamp
Enables fine and flexible adjustment of flow rates
Offers spike protection for safe disposal
With tube dock designed to support handling during priming
Patient connector
With Luer Lock or screw tight Spinlock adapter to prevent inadvertent disconnection (refer to available versions)
With back check valve to reduce the risk of back flow (versions with back check valve)
